Description

Key Features:

✅ High-Precision Load Cell Brake – 100KG load cell for maximum accuracy and realism.
✅ Hall Effect Sensors – Provides precise throttle and brake pedal movements.
✅ Adjustable Brake Force – Customize the resistance for a more realistic brake feel.
✅ Fully Adjustable Pedals – Adjust pedal angles, positions, and travel to suit personal preferences.
✅ CNC-Machined Pedal Plates – High-precision CNC plates for improved durability and performance.
✅ Modular Design – Allows for future upgrades and customization (e.g., optional clutch module).
✅ Solid Aluminum Alloy Construction – Robust, lightweight, and built to last.
✅ Floor Mounting – Provides stability and an immersive racing experience.
✅ Pedal Control Box Included – Manage and customize pedal inputs directly through the control box.
✅ Comprehensive Compatibility – Works with a variety of sim racing setups and platforms.

Product Specifications:

• Product Name: P1000 / P1000i
• Resolution: 12Bit (4096) [High accuracy sensor]
• USB Connection:
  • PC
  • SIMAGIC Wheelbase (via Bus Port)
• Adjustable Travel: Supported
• Adjustable Spring Force Level:
  • Clutch
  • Brake
• Sensors:
  • Throttle: Hall Angle Sensor
  • Brake: Hall Angle Sensor / Loadcell Sensor
  • Clutch: Hall Angle Sensor
• Loadcell Sensor: 100KG
• Haptic Pedal Reactor: Optional
• Hydraulic Cylinder: Optional
• Inverted Installation: P1000i only
• Pedal Plate: Anodized Aluminum Alloy
• Angle/Position Adjustment: Supported
• Adjustable Linearity: Supported
• Adjustable Brake Force: Supported
• Adjustable Deadzones: Supported
• Pedal Control Box: Included

Building Materials:

• Pedals: CNC Aluminum Alloy

Dimensions (L x W x H):

• P1000: 334.8mm x 336mm x 267mm
• P1000i: 348mm x 489.8mm x 368.5mm

Net Weight:

• P1000: 5.65kg
